DG4000 Series — Waveform Generator
DG4064B
SKU: DG4064B
$11,000.00 En stock
48 data + 16 event channels (64 total)
700 Mbps/ch data rate
Protocol stimulus mode for automated testing
SDK available for custom integration
U.S. based engineering support
About the DG4064B
The DG4064B is a 64-channel digital pattern generator (48 data + 16 event channels) for test stimulus creation, protocol simulation, and automated production testing. It supports protocol stimulus mode and includes an SDK for integration into custom test systems.
Key Highlights
- 48 data + 16 event channels (64 total) at 700 Mbps/ch
- Protocol stimulus mode
- SDK for automation (Python, LabVIEW, C)
| Channels | 48 data + 16 event |
| Data Rate | 700 Mbps/ch |
| Interface | USB 3.0 |
Compare DG4000 Series Models
See how the DG4064B compares to other models in the DG4000 Series series.
| Specification | DG4064B Current | DG4096B | DG4128B |
|---|---|---|---|
| Data Channels | 48 | 80 | 112 |
| Event Channels | 16 | 16 | 16 |
| Max Data Rate | 700 Mbps/ch | 700 Mbps/ch | 700 Mbps/ch |
| Clock Range | 1 Hz – 2.4 GHz | 1 Hz – 2.4 GHz | 1 Hz – 2.4 GHz |
| Pattern Depth | 256 Mb/ch | 256 Mb/ch | 256 Mb/ch |
| Probe Output | 0.9–5.0 V | 0.9–5.0 V | 0.9–5.0 V |
| List Price | $11,000 | $12,100 | $13,800 |
Preset patterns: I2C, MIPI I3C, MIPI RFFE, PMBus, PWM, SPI
