DG4000 Series — Waveform Generator
DG4128B
SKU: DG4128B
$13,800.00 En stock
112 data + 16 event channels (128 total)
700 Mbps/ch data rate
Protocol stimulus mode for automated testing
SDK available for custom integration
U.S. based engineering support
About the DG4128B
The DG4128B is the highest channel count digital pattern generator in the lineup — 128 channels (112 data + 16 event) at 700 Mbps/ch for the most demanding stimulus and validation applications.
Key Highlights
- 112 data + 16 event channels (128 total) at 700 Mbps/ch
- Protocol stimulus mode
- SDK for automation
| Channels | 112 data + 16 event |
| Data Rate | 700 Mbps/ch |
| Interface | USB 3.0 |
Compare DG4000 Series Models
See how the DG4128B compares to other models in the DG4000 Series series.
| Specification | DG4064B | DG4096B | DG4128B Current |
|---|---|---|---|
| Data Channels | 48 | 80 | 112 |
| Event Channels | 16 | 16 | 16 |
| Max Data Rate | 700 Mbps/ch | 700 Mbps/ch | 700 Mbps/ch |
| Clock Range | 1 Hz – 2.4 GHz | 1 Hz – 2.4 GHz | 1 Hz – 2.4 GHz |
| Pattern Depth | 256 Mb/ch | 256 Mb/ch | 256 Mb/ch |
| Probe Output | 0.9–5.0 V | 0.9–5.0 V | 0.9–5.0 V |
| List Price | $11,000 | $12,100 | $13,800 |
Preset patterns: I2C, MIPI I3C, MIPI RFFE, PMBus, PWM, SPI
Descargas
Controladores
Hojas de datos
No está seguro de cual instrumento es adecuado para su aplicación?
Nuestro equipo de ingeniería puede ayudarle a elegir el instrumento adecuado para sus necesidades de protocolo, número de canales y rendimiento.
