DG4000 Series — Waveform Generator
DG4096B
SKU: DG4096B
$12,100.00 En stock
80 data + 16 event channels (96 total)
700 Mbps/ch data rate
Protocol stimulus mode for automated testing
SDK available for custom integration
U.S. based engineering support
About the DG4096B
The DG4096B is a 96-channel digital pattern generator (80 data + 16 event channels) for wider bus stimulus and complex test scenarios. Protocol stimulus mode and SDK support for automated testing.
Key Highlights
- 80 data + 16 event channels (96 total) at 700 Mbps/ch
- Protocol stimulus mode
- SDK for automation
| Channels | 80 data + 16 event |
| Data Rate | 700 Mbps/ch |
| Interface | USB 3.0 |
Compare DG4000 Series Models
See how the DG4096B compares to other models in the DG4000 Series series.
| Specification | DG4064B | DG4096B Current | DG4128B |
|---|---|---|---|
| Data Channels | 48 | 80 | 112 |
| Event Channels | 16 | 16 | 16 |
| Max Data Rate | 700 Mbps/ch | 700 Mbps/ch | 700 Mbps/ch |
| Clock Range | 1 Hz – 2.4 GHz | 1 Hz – 2.4 GHz | 1 Hz – 2.4 GHz |
| Pattern Depth | 256 Mb/ch | 256 Mb/ch | 256 Mb/ch |
| Probe Output | 0.9–5.0 V | 0.9–5.0 V | 0.9–5.0 V |
| List Price | $11,000 | $12,100 | $13,800 |
Preset patterns: I2C, MIPI I3C, MIPI RFFE, PMBus, PWM, SPI
Descargas
Controladores
Hojas de datos
No está seguro de cual instrumento es adecuado para su aplicación?
Nuestro equipo de ingeniería puede ayudarle a elegir el instrumento adecuado para sus necesidades de protocolo, número de canales y rendimiento.
