LA4136E
Série LA4000 — Logic Analyzer

LA4136E

SKU: LA4136E

$12,100.00 Em estoque
Solicitar orçamento
136 channels with 4 GHz timing analysis
Tier I bus trigger and protocol analyzer
Cascade multiple units for expanded channel count
100+ protocol decoders
U.S. based engineering support
Datasheet (PDF) User Manual (PDF)

About the LA4136E

The LA4136E doubles the channel count to 136 channels at 4 GHz timing, ideal for wide parallel bus interfaces like DDR address/data lines, large FPGA I/O validation, and LCD driver testing.

Key Highlights

  • 136 channels at 4 GHz timing analysis
  • Cascade multiple units for expanded channel count
  • Ideal for DDR, FPGA, and LCD driver validation
  • Optional LVDS input pod
Channels 136
Timing Analysis 4 GHz
State Analysis 400 MHz
Protocol Decode Tier I (100+ total)
Cascading Yes (multi-unit synchronized)
Interface USB 3.0
OS Support Windows 10 / 11 · Linux (beta)
Suporte para Linux disponível Beta

Um aplicativo nativo para Linux está disponível em beta.

Baixar no GitHub

Suporte de protocolos

90+ protocolos decodificados · 90+ com disparo por hardware

96 protocolos suportados·DDecodificação   TDisparo   EVValidação elétrica

ProtocoloDecodificaçãoDisparo
I2CDT
MIPI I3CDT
SPIDT
UARTDT

Compare Série LA4000 Models

See how the LA4136E compares to other models in the Série LA4000 series.

Specification LA4068E LA4068B LA4136E Current LA4136B
Channels 68 68 136 136
Timing Analysis 4 GHz 4 GHz 4 GHz 4 GHz
State Analysis 400 MHz 400 MHz 400 MHz 400 MHz
Memory 32 Gb 32 Gb 32 Gb 32 Gb
Bus Trigger Tier I Tier I, II Tier I Tier I, II
Protocol Analyzer Tier I Tier I, II Tier I Tier I, II
Cascading Yes Yes Yes Yes
List Price $8,700 $11,000 $12,100 $13,800
View all Série LA4000 models →

Comparar

See how the LA4136E stacks up against the competition.

LA4000 vs Saleae Logic Pro 16

Protocolos suportados

I2C SPI CAN FD UART MIPI I3C eMMC CAN 2.0B I2S eSPI SMBus PMBus SD UHS QSPI SVID MIPI RFFE DP AUX Modbus JTAG MIPI SPMI PDM MIPI SoundWire PCM TDM Ethernet MCTP LTPI MCTP Control PLDM M-PESTI NCSI SPDM USB4/TBT3 SB MIPI D-PHY MIPI DSI LP MII RMII RGMII GMII SGMII Power Sequence BiSS-C HDLC ProfiBus PWM NAND Flash Serial NOR Flash SPI NAND 10BASE-T1S OA3p OPEN Alliance TC6 USB 1.1 SWD
